Specification		XJE200B	XJE200T
Optical System	Infinity achromatic optical system	●	●
Viewing Head	Binocular, Inclined at 30 °, Rotatable 360°, Interpupilary Distance: 54~75mm	●
Viewing Head	Trinocular, Inclined at 30 ° , Rotatable 360°, Interpupilary Distance: 54~75mm, Light Distribution: 20/80		●
Eyepiece	PL 10X/18mm with ±5 degrees diopter control	●	●
Eyepiece	PL 10X/20mm with ±5 degrees diopter control
Polarization	Simply Polarizer
Nosepiece	Backward quadruple nosepiece	●	●
Nosepiece	Backward quintuple nosepiece
Objective	Plan Achromatic 4X/0.10	●	●
	Plan Achromatic 10X/0.25	●	●
	Plan Achromatic 40X/0.65	●	●
	Plan Achromatic 100X/1.25(Oil,S)	●	●
	Plan Achromatic 4X/0.10 WD=21mm	○	○
	Plan Achromatic 10X/0.30 WD=5mm	○	○
	Plan Achromatic 20X/0.65 WD=8.8mm	○	○
	Plan Achromatic 40X/0.70(S) WD=0.66mm	○	○
	Plan Achromatic 100X/1.30 (S,O) WD=0.36mm	○	○
Stage	Coaxial mechanical stage in140X132mm size and 76×50mm travel range.	●	●
Condenser	Koehler N.A.1.25 condenser(with socket for phase contrast and dark field sliders)	●	●
Filter	Blue(45mm)	○	○
	Green(45mm)	○	○
	Neutral(45mm)	○	○
Focus System	Coaxial coarse and fine focusing adjustment,with limited and tension adjustment. coarse adjustment range: 25mm, fine adjustment precision：0.002mm.	●	●
Illumination	Main supply 100V-240V, 3 watt LED lamp with intensity control (fixed center)	●	●
	Main supply 100V-240V, philips 6V/20W halogen lamp with intensity control (fixed center)	●	●
	Halogen	○	○
C-mount	1X	○	○
	0.5X	○	○
	0.35	○	○
Weight/ Volume	57.155.427.8CM 10.5KGS
